Overview
LB1908 can connect to one RGB LED, and boasts an impressive 8kHz PWM rate. The control circuit comes in a SOP8 package, allowing for more flexibility with LED choice.
LB1908 pixel protocol
Specifications
PixLite Mk1 | |
PixLite Mk2 | |
PixLite Mk3 | |
Clock Type | Data-Only |
Color Resolution | 8 Bits |
Current Control | |
Physical Package | SOP8 |
RGB | |
RBGW | |
Input Voltage | 12V |
Output Pixel Voltage | 12V |
PWM Rate | 8000Hz |
Suitable Camera | Up to 266fps |
Data Transfer Rate | 800kbps |
Redundant Data Line |
Considerations for Use
Advantages
- 12V operation, allows for long cable lengths and long chains of pixels
- High PWM rate allows for filming these pixels with cameras up to 86fps
- Redundant data line reduces chance of entire strip failure
Disadvantages
- Data-only restricts refresh rates to be limited by the speed of the protocol, which can be slow
- Only 8 bits of data for each color makes dimming curves less smooth
PixLite Support
Are you looking for LB1908 pixel drivers that work with Art-Net or sACN?
All PixLite Mk3 products support LB1908 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
