LED Pixel Protocol TLS3001

Overview

This pixel protocol was designed by Teralane Semiconductor Inc. in China The control circuit can come in a SOP8/SOP10/SOP14 package, depending on which functions are being used, allowing for more flexibility with LED choice.

➤ Check out Advatek's TLS3001 PixLite Bright LED Fixtures below

PixLite® Bright String

PixLite® Bright String

50 count pixel string in “bullet” style form factor with individually controllable RGB pixels.

TLS3001 graphic

TLS3001 graphic

Specifications

PixLite Mk1

PixLite Mk2

PixLite Mk3

Clock Type

Data-Only

Color Resolution

12 Bits

Current Control

Physical Package

SOP8/10/14

RGB

RBGW

Input Voltage

5V

Output Pixel Voltage

5 - 17V

PWM Rate

1000Hz

Suitable Camera

Up to 34fps

Data Transfer Rate

500 - 1000kbps

Redundant Data Line

(SOP14 only)

Considerations for Use

Advantages

  • High PWM rate allows for filming these pixels with cameras up to 34fps
  • Up to 17V, allowing for long cable lengths
  • Option for redundant data line reduces chance of entire strip failure
  • 12 bits of data for each color makes dimming curves more smooth

Disadvantages

  • Data-only restricts refresh rates to be limited by the speed of the protocol, which can be slow

Operational Behavior

On start-up, only the first TLS3001 pixel in a chain will illuminate for a second, while the pixels initialize themselves. When initialization has completed, all pixels will proceed to respond to their incoming data.

PixLite Support

Are you looking for TLS3001 pixel drivers that work with Art-Net or sACN?

All PixLite Mk1, Mk2, and Mk3 products support TLS3001 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
