Overview
This pixel protocol was designed by Titan Micro Electronics in China. It is an improved design of its previous version, TM1804, offering RGBW capability as well as a faster PWM. The control circuit comes in a SOP8 package, allowing for more flexibility with LED choice.
Current Control
TM1814 has the ability to digitally control the current of the connected LEDs. Use the 6-bit current control per color to lower the brightness without sacrificing resolution, and tune the current of individual colors, allowing for more accurate color mixing. This individual current control can be set when configuring your PixLite Mk3 controller.
TM1814 pixel protocol
Specifications
PixLite Mk1 | |
PixLite Mk2 | |
PixLite Mk3 | |
Clock Type | Data-Only |
Color Resolution | 8 Bits |
Current Control | Per Color: 6 Bits |
Physical Package | SOP8 |
RGB | |
RBGW | |
Input Voltage | 5V |
Output Pixel Voltage | 5 - 32V |
PWM Rate | 1000Hz |
Suitable Camera | Up to 34fps |
Data Transfer Rate | 500 - 800kbps |
Redundant Data Line |
Considerations for Use
Advantages
- Up to 32V, allowing for very long cable lengths
- High PWM rate allows for filming these pixels with cameras up to 34fps
- Presence of white LED allows for higher brightness and more color mixing options
Disadvantages
- Data-only restricts refresh rates to be limited by the speed of the protocol, which can be slow
- Only 8 bits of data for each color makes dimming curves less smooth
- No redundancy in data
PixLite Support
Are you looking for TM1814 pixel drivers that work with Art-Net or sACN?
All PixLite Mk2 and Mk3 products support TM1814 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
