LED Pixel Protocol UCS1903

Overview

This pixel protocol was designed by Lianxinke in China. The control circuit comes in a SOP8 package, allowing for more flexibility with LED choice.

Specifications

Considerations for Use

Advantages

• Up to 12V, allowing for long cable lengths

Disadvantages

• Low PWM rate makes theses pixels unsuitable for cameras
• Data-only restricts refresh rates to be limited by the speed of the protocol, which can be slow
• Only 8 bits of data for each color makes dimming curves less smooth
• No redundancy in data

PixLite Support

Are you looking for UCS1903 pixel drivers that work with Art-Net or sACN?

All PixLite Mk1, Mk2, and Mk3 products support UCS1903 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
