Overview
This pixel protocol was designed by Lianxinke in China. UCS2912 has a control circuit that comes in a SOP16 package, allowing for more flexibility with LED choice.
UCS2912 pixel protocol
Specifications
PixLite Mk1 | |
PixLite Mk2 | |
PixLite Mk3 | |
Clock Type | Data-Only |
Color Resolution | 8 Bits |
Current Control | |
Physical Package | SOP16 |
RGB | |
RBGW | |
Input Voltage | 5V |
Output Pixel Voltage | 5 - 24V |
PWM Rate | 1600Hz |
Suitable Camera | Up to 54fps |
Data Transfer Rate | 800kbps |
Redundant Data Line |
Considerations for Use
Advantages
- Up to 24V, allowing for very long cable lengths
- High PWM rate allows for filming these pixels with cameras up to 54fps
Disadvantages
- Data-only restricts refresh rates to be limited by the speed of the protocol, which can be slow
- Only 8 bits of data for each color makes dimming curves less smooth
- No redundancy in data
PixLite Support
Are you looking for UCS2912 pixel drivers that work with Art-Net or sACN?
All PixLite Mk3 products support UCS2912 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
