LED Pixel Protocol UCS512B

Overview

This pixel protocol was designed by Lianxinke in China. It uses a non-differential DMX512 protocol to drive pixel chips. The control circuit comes in a SOP8 package, allowing for more flexibility with LED choice.

UCS512B pixel protocol - Advatek Lighting

UCS512B pixel protocol

Specifications

PixLite Mk1

PixLite Mk2

PixLite Mk3

Clock Type

Serial DMX (Single Wire)

Color Resolution

8 Bits

Current Control

Physical Package

SOP8

RGB

RBGW

Input Voltage

5V

Output Pixel Voltage

5 - 24V

PWM Rate

3000Hz

Suitable Camera

Up to 100fps

Data Transfer Rate

250 - 750kbps

Redundant Data Line

Considerations for Use

Advantages

  • Up to 24V, allowing for very long cable lengths
  • High PWM rate allows for filming these pixels with cameras up to 100fps

Disadvantages

  • Data-only restricts refresh rates to be limited by the speed of the protocol, which can be slow
  • Only 8 bits of data for each color makes dimming curves less smooth
  • No redundancy in data
  • Operation relies on addressing of the pixels to be correct from the factory (See Operational Behavior below)

Operational Behavior

UCS512B will work with the generic DMX512 protocol as is, but this assumes correct factory set addressing of the individual pixels (addressing is usually pre-set at the factory in the pixels themselves, by using the external addressing line).

PixLite Support

Are you looking for UCS512B pixel drivers that work with Art-Net or sACN?

All PixLite Mk2 and Mk3 products support UCS512B as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.

Note: When configuring your PixLite device, select 'DMX512' as your Pixel Type. This is the equivalent protocol that will allow you to use UCS512B pixels.
