Overview
This pixel protocol was designed by World Semi in China. WS2812 offers many of the benefits the WS28xx series is famous for, as well as being the first in the series to offer an integrated LED design. Typically, users will choose WS2813 or above for higher quality, however WS2812 is still one of the most common protocols for pixel lighting displays. The control circuit and LEDs are integrated in a 5050 SMD package, which provides a small physical footprint for each pixel.
WS2812 pixel protocol
Specifications
PixLite Mk1 | |
PixLite Mk2 | |
PixLite Mk3 | |
Clock Type | Data-Only |
Color Resolution | 8 Bits |
Current Control | |
Physical Package | SMD5050 with integrated LEDs |
RGB | |
RBGW | |
Input Voltage | 5V |
Output Pixel Voltage | 5 - 12V |
PWM Rate | 400Hz |
Suitable Camera | Unsuitable for cameras |
Data Transfer Rate | 800kbps |
Redundant Data Line |
Colors
Color | Brightness | Wavelength |
|---|---|---|
Red | 550 – 700 mcd | 620 – 630 nm |
Green | 1100 – 1400 mcd | 515 – 530 nm |
Blue | 200 – 400 mcd | 465 – 475 nm |
Considerations for Use
Advantages
- Up to 12V, allowing for long cable lengths
Disadvantages
- Data-only restricts refresh rates to be limited by the speed of the protocol, which can be slow
- Low PWM rate makes theses pixels unsuitable for cameras
- Only 8 bits of data for each color makes dimming curves less smooth
- No redundancy in data
